Diagnosis of diabetic retinopathy

Reading time: 3 min

The diagnosis of diabetic retinopathy is closely associated with its stage. The disease is diagnosed and classified when initial signs of the condition are observed in the fundus of the eye, normally using photography. When fluid is also detected in the inner retina, diabetic macular oedema is diagnosed in association with the retinopathy.

Tests used to diagnose Diabetic Retinopathy

The diagnosis of diabetic retinopathy requires a series of complementary tests, because the condition cannot be observed externally as it affects the very back of the eye (the eye fundus). Of all these tests, only fluorescein angiography causes side effects and requires any special care. The main techniques used are:

Slit lamp to study the back of the eye

Indirect biomicroscopy of the eye fundus. This technique uses a slit lamp and condenser lens to provide a view of the eye fundus. Only the person carrying out the examination, normally the ophthalmologist, can see the image in the eyepiece.


Retinography. Photography of the eye fundus using a camera, hence the results can be saved. Depending on the model type, the patient’s pupils may need to be dilated. The field of view can range from 30–45° (conventional models) up to 210° (ultra-wide field systems). This is the main technique used to screen for retinopathies in people with diabetes.

Ocular angiography

Fluorescein retinal angiography. This method is similar to retinography, but the contrast agent fluorescein is injected into a vein. When this dye reaches the fundus of the eye it highlights any changes in retinal blood flow and, chiefly, the presence of neovascularisation and haemorrhages. This test cannot be performed on people with a fluorescein allergy and must be conducted with special care in patients with kidney problems. Patients who undergo this test may produce yellow urine for the next 24 hours.

Optical coherence tomography

Optical coherence tomography. This technique uses a light beam to scan the inner retina (macula). It produces cross-sectional images of the different layers in the retina. It is particularly useful for examining diabetic macular oedema.

Fundus, retina

Optical coherence tomography angiography. This recently developed test involves processing the images obtained by scanning the retina’s layers. Blood circulation in the retina can be characterised without having to inject a dye.

Substantiated information by:

Anna Sala Puigdollers
Marc Figueras Roca
Victoria Hernández Grima

Published: 3 July 2018
Updated: 3 July 2018
